INSTRUMENT PANEL (continued)
3 Oil level display
To be valid, the reading must be
taken with the vehicle on level
ground and after the engine has
been switched off for some time.
When the engine is started and
for about thirty seconds
afterwards.
- if the level is correct,the
display indicates 'Oil level OK'
(to obtain a more precise
reading refer to information on
the Oil level in Section 4).
- if the level is at minimum,the
“oil ok” message is not
displayed; the dashes and
“adjust oil level” are displayed
together with the
warning light.
Top up with fluid as soon as
possible.
3 Trip computer and warning
system
After 30 seconds, the display
will switch over to display the
trip computer: refer to “Tri p
computer” in Section 1.
4 Rev counter
(scale ×1000)
5 Right turn signal
indicator light
Oil pressure warning
light
Itcomesonwhenthe
engine is started then goes out
after a few seconds. If it comes
on when the vehicle is being
driven, accompanied by the
warning light and a
beep, it is essential to stop and
switch off the ignition. Check
the oil level. If the level is
normal, the warning light is
being lit by something else.
Contact a RENAULT Dealer.
5 Battery charge indicator
light
This comes on when the
engine is started then goes out as
soon as the engine is running. If
it comes on when the vehicle is
being driven, and is
accompanied by the
warning light and a beep, it
indicates that the electrical
circuit is overcharged or
undercharged.
Stop and have the circuit
checked.
