INSTRUMENT PANEL (continued)
10 Doors/tailgate warning light or
multifunction display
(depending on vehicle)
Doors/tailgate warning light
Shows when a door or the
tailgate is open or not closed
properly.
OR
Multifunction display
This indicates that an opening
element (door or tailgate) is
open or not properly closed,
displays the tyre pressures (refer
to “Tyre Pressure Monitor” in
Section 2) and the gear selected
(for vehicles with an automatic
gearbox).
11 Warning light
This lights up when the
engine is started and
goes out after a few seconds.
It can light up with other
warning lights or messages on
the instrument panel.
If it comes on when the vehicle
is being driven, it is advisable to
visit your RENAULT Dealer as
soon as possible.
12 Front fog lights
indicator light
Rear fog light indicator
light
Dipped beam headlight
indicator light
Headlight main beam
indicator light
13 Coolant temperature indicator
In normal use, the needle
should be below zone 13a.
Under severe conditions the
needle may approach this zone.
This is not serious unless the
warning light comes on
accompanied by a message on
the instrument panel and a
beep.
