5.29
INTERIOR LIGHTING: changing bulbs (3/4)
Glove box light
(depending on the vehicle)
Unclip the light 8 using a flat-blade
screwdriver or similar, by pressing on
the tab to move the light towards the
inside of the unit.
Disconnect the light.
Press the tab 9 to release the lens 11
and gain access to the bulb 10.
Bulb type 10:W5W.
The bulbs are under pres-
sure and can break when
replaced.
Risk of injury.
9
10
11
8
