5.21
7 Reversing light
Pear-shaped bayonet bulb P 21 W
or,
Rear fog light
(depending on vehicle)
Pear-shaped, bayonet type P 21 W
bulb.
Refitting
To refit, proceed in the reverse order,
taking care not to damage the wiring.
REAR LIGHTS: replacing the bulbs(1/5)
Rear lights
Open the tailgate and unscrew the
nuts 1, then release the light unit 2 by
pulling it out.
Release the clips 3 to remove the bulb
holder 4.
5 Side light and brake light
Pear-shaped, bayonet type bulb with
two P 21/5 W filaments.
6 Direction indicator light
Pear-shaped, bayonet type P 21 W
or PY 21 W bulb (depending on ve-
hicle).
The bulbs are under pres-
sure and can break when
replaced.
Risk of injury.
1
2
3
3
4
5
6
7
