INSTRUMENT PANEL (continued)
The presence and operation of the warning and indicator lights described below depend on the vehicle
equipment and country.
1 Dipped beam headlight
indicator light
Main beam headlight
indicator light
Rear fog light indicator
light
Front fog light indicator
light
Anti-lock braking
warning light
This lights up when the
ignition is switched on and
then goes out. If it lights up
when you are driving, it
indicates a fault in the
Anti-lock Braking System.
Braking will then be as normal,
without the ABS system.
Contact your RENAULT Dealer
as soon as possible.
1 Rear screen demisting
indicator light
2 Rev counter
(scale ×100)
3 Fuel level gauge
4 Coolant temperature indicator
In normal use, the needle
should be below zone 4a.
Undersevereusetheneedle
may enter this zone. This is not
serious unless the warning
light comes on.
5 Speedometer (miles or km per
hour)
Overspeed buzzer
Depending on the vehicle, a
buzzer sounds for
approximately 10 seconds
every 40 seconds, as long as the
vehicle is travelling in excess of
75 mph (120 km/h).
6 Airbag warning light
This lights up when the
ignition is switched on
and goes out after a few
seconds.
If it does not light up when the
ignition is switched on, or
lights up when the engine is
running, this indicates a fault
in the system. Contact your
RENAULT Dealer as soon as
possible.
Not used
Seat belt not fastened
warning light
This lights up constantly,
and, when the vehicle reaches a
speed of approximately 6 mph
(10 km/h), depending on the
vehicle, it will flash and a beep
will sound for approximately
90 seconds before the light
returns to being constantly lit.
Door(s) open warning
light
Not used
