3.06
AIR CONDITIONING
Controls
A Heat setting adjustment
B Distribution of air in the
passenger compartment
C Switching on the air conditioning
D Air conditioning operation
tell-tale light
E Adjusting the amount of air
supplied to the passenger
compartment
Adjustments for heat setting
Move control A.
To the right: Maximum possible
temperature.
To the left: Minimum possible
temperature.
