3.02
AIR VENTS (air outlets)
1 - Left-hand front window demister
2 - Left-hand side air vent
3 - Windscreen demisting vents
4 - Central air vents
5 - Heating/ventilation control unit
6 - Right-hand side air vent
7 - Right-hand front window demister
8 - Footwell heater outlets for front
and rear passengers
