3.36
REAR PARCEL SHELF - UTILITY VERSIONS
Shelf A is moved as described
above.
To remove shelf B,pressthetwo
tabs 1 and take out the shelf.
To refit, proceed in reverse order,
ensuring that the two guides 2 are
positioned at the partition grille
tube 3.
