Aérateurs (sorties d’air) (X10 - Renault)
Jaune Noir Noir texte
Air vents
Air vENTS: air outlets (1/2)
1 side air vent.
2 side window demister outlet.
3 centre air vents.
4 windscreen demisting vents.
5 passenger footwell heater outlets.
6 control panel.
1 2 3
4
2
1
5
6
5
