Renault zoe - Electric Vehicle: Introduction

electric vehicle
presentation ....................................(up to the end of the DU)
12 volt battery .......................................(up to the end of the DU)
traction battery ......................................(up to the end of the DU)
»400 volt» electrical circuit ...................(up to the end of the DU)
charging socket ....................................(up to the end of the DU)
1.2
ENG_UD33253_3
Présentation (X10 - Renault)
Jaune Noir Noir texte
Electric vehicle: introduction
1 Electric charging connection
2 Electric motor
3 Secondary 12V battery
4 400 V traction battery
5 Orange electrical power cables
El ECTri C vEhiCl E: introduction (1/5)
1
2
3
5
4
