Cache-bagages : versions société (X10 - Renault)
Luggage cover
The luggage compartment cover con-
sists of a rigid section A and a folding
section B.
The luggage cover is in the unfolded
position.
The luggage compartment cover is
removed.
To remove it: with the cover in the folded
position and holding it horizontally:
– pull one side of the luggage compart-
ment cover towards you, pivoting it
slightly;
– then pull the other side of the lug-
gage compartment cover to com-
pletely detach it from its housing.
l Ugg Ag E COmPAr TmENT COvEr : utility versions
Do not place any objects,
especially heavy or solid
objects on the luggage
compartment cover. These
may pose a risk to the vehicle occu-
pants if the driver has to brake sud-
denly or if the vehicle is involved in
an accident.
The luggage compartment cover is
in the folded position.
To fold it:
– lift shelf A slightly and pull it towards
you to remove;
– then fold section B back on itself.
A
B
