card: battery..........................................(up to the end of the DU)
»hands-free» card: battery ...................(up to the end of the DU)
»hands-free» card: use.........................(up to the end of the DU)
5.13
ENG_UD53730_4
Carte renault : piles (L38 ZE - X10 - Renault)
“Hands-free” card: battery
Operating faults
If the battery is too weak to ensure cor-
rect operation, you can still start (insert
the RENAULT card in the card reader)
and lock/unlock the vehicle (refer to the
information on "Locking/unlocking the
doors" in Section 1).
“hANDS-Fr EE” CAr D: battery (1/2)
replacing the battery
When the message “Keycard battery
low” appears on the instrument panel,
replace the battery in the card:
– press the 1 button while pulling on
the emergency key 2;
– unclip the cover 3 using the tab 4;
– remove the battery by pressing on
one side (movement A), and lifting
the other (movement B);
1
2
– replace it according to the direction
and template indicated inside the
cover. 3.
When refitting, proceed in the reverse
order, then depending on the vehicle,
press one of the buttons on the card
four times, close to the vehicle: the
message will disappear.
Check that the cover is clipped shut.
A
B
3
4
The batteries are available from approved Dealers, and their service life approximately two years. Check that there is no dye
on the battery: risk of an incorrect electrical contact.
If they need to be replaced,
be sure to use the same
or equivalent type of bat-
tery (consult an Approved
Dealer).
When replacing:
– make sure that the batter-
ies are correctly inserted.
There is a risk of explo-
sion.
– if the flap does not close correctly,
do not use and keep out of reach
of children.
