Sécurité enfants : choix de la fixation du siège enfant (X10 - Renault)
Chil D SAFETY: choosing a child, baby seat mounting (2/2)
The ISOFIX anchorage points have been exclusively designed for child seats with the ISOFIX system. Never fit a dif-
ferent type of child seat, seat belt or other objects to these anchorage points.
Check that nothing is obstructing the anchorage points.
If your vehicle has been involved in a road accident, have the ISOFIX anchorage points checked and replace your child seat.
The two rings 1 are located between
the seatback and the seat base of the
seat and are identified by a marking.
1
The third ring is used to attach the
upper strap on some child seats: you
must attach hook 2 on ring 3 for a rear
seat and ring 4 for a front seat, then
tighten the strap.
2
3
4
