Sécurité enfants : installation du siège enfant (X10 - Renault)
Chil D SAFETY: fitting a child seat (4/6)
The table below summarises the information already shown on the diagram on the previous page, to ensure the regula-
tions in force are respected.
Type of child seat
Weight of
the child
Seat size
Front passenger
seat (5) (1)
rear side
seats
rear centre
seat
Carrycot fitted across the ve-
hicle
Group 0
< 10 kg F, G X U - IL (2) X
rear-facing shell seat
Group 0 or 0+
< 10 kg and
< 13 kg
E U - IL U - IL (3) U (3)
rear-facing seat
Group 0+ and 1
< 13 kg and 9 to
18 kg
C U - IL U (3) U (3)
D U - IL U - IL (3) U (3)
Forward-facing seat
Group 1
9 to 18 kg A, B, B1 IUF - IL U - IUF - IL (4) U (4)
Booster seat
Group 2 and 3
15 to 25 kg and
22 to 36 kg
- X U (4) U (4)
X = Seat not suitable for fitting child seats.
U = Seat which allows a child seat with “Universal” approval to be installed using a seat belt; check that it can be fitted.
iUF/il = On equipped vehicles, seat which allows an approved “Universal/semi-universal” or vehicle specific” child seat to be at-
tached using the ISOFIX system; check that it can be fitted.
(1) raise the seat to the maximum and position it as far back as possible, tilting the seatback slightly (approximately 25°).
(2) A carrycot can be installed across the vehicle and will take up at least two seats. Position the child with his or her feet nearest
the door.
(3) Move the front seat as far forward as possible to install a rear-facing child seat, then move back the seat in front as far as it will
go, although without allowing it to come into contact with the child seat.
(4) Forward-facing child seat; position the seatback of the child seat in contact with the seatback of the vehicle seat. Adjust the
headrest, or remove it if necessary. Do not push the front seat more than halfway back on its runners and do not recline the
seatback more than 25°.
(5) riSK OF DEATh Or SEriOUS iNJUr Y: before installing a rear-facing child seat in the front passenger seat, make
sure the airbag has been deactivated (refer to the information on “Child safety: front passenger airbag deactivation/
activation” in Section 1).
