Renesas RH850 Series User Manual

Getting Started
3.1 Bill of Materials
The SENT application board package contains the following type and quantity of
materials.
Table 3. Bill of Materials
#
Name
Quantity
1
RH850 SENT Application Board
1
2
Jumper (in separate bag)
5
3
Rubber Pads
4
4
Ribbon cable for X1X Main Board
1
3.2 Basic Setup for the SENT Extension Board
Before you start to operate with the SENT application board, please check the
initial jumper settings according to the following table.
Table 4: Initial Jumper Settings
Name
Signal/Jumper name
Jumper setting
Board Sensor
Disconnect
TOP (J1)
CLOSE
BR1P (J4)
CLOSE
BOT (J5)
CLOSE
BR1N (J6)
CLOSE
SENT disconnect
J7
CLOSE
CMV error
J2
CLOSE
VDDEUV fault
J3
CLOSE
External Sensor
TOP (CN2)
OPEN
BR1P (CN2)
OPEN
BOT (CN2)
OPEN
BR1N (CN2)
OPEN

Renesas RH850 Series Specifications

General

Core	RH850
Operating Voltage	2.7V to 5.5V
Package Options	LQFP, BGA
Communication Interfaces	CAN, LIN, FlexRay, Ethernet, SPI, I2C, UART
Target Applications	Automotive, Industrial
Timers	Multiple timers
ADC	12-bit, 10-bit
Security Features	Hardware Security Module (HSM)
Safety Features	Memory Protection
