RL78/G13 Safety Function (Frequency Detection)
Caution: For details on the register setup procedures, refer to RL78/G13 User's Manual: Hardware.
Controlling the channel trigger operation
 Tim
er channel stop register 5 (TT05)
Select the TAU0 stop trigger.
Symbol: TT0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 0 0 0 TT
H03
0 TT
H01
0 TT
07
TT
06
TT
05
TT
04
TT
03
TT
02
TT
01
TT
00
0 0 0 0 1 0 1 0 1 1 1 1 1 1 1 1
Bit 5
TT05 Channel 5 stop trigger
0 No trigger operation
1 Operation is stopped (stop trigger is generated).
Caution: For details on the register setup procedures, refer to RL78/G13 User's Manual: Hardware.
R01AN0956EJ0100 Rev. 1.00 Page 32 of 70
Feb. 27, 2012
