8
Note 1 Performance specification is tested at a standard test velocity of 480 mm/min (18.9 in/min) with a 35 mm stylus. Significantly
higher velocity is possible depending on application requirements.
Note 2 Trigger force, which is critical in some applications, is the force exerted on the component by the stylus when the probe
triggers. The maximum force applied will occur after the trigger point (overtravel). The force value depends on related
variables including measuring speed and machine deceleration. Trigger force is measured with a 50 mm (1.97 in) stylus.
Note 3 These are the factory settings; manual adjustment is not possible.
NOTE: For stylus recommendations, refer to the Styli and accessories technical specication
(Renishaw part no. H-1000-3200).
Specication
