9
3. Unscrew butterfly nut tilt to desired angle and lock butterfly nut
To maximize the output, adjust the angle of the suitcase regularly to track the sun’s movement
throughout the season
Summer
πœƒ = πΏπ‘Žπ‘‘π‘–π‘‘π‘’π‘‘π‘’ – 15Β°
Fall and Spring
πœƒ = π‘Žπ‘‘ π‘™π‘Žπ‘‘π‘–π‘‘π‘’π‘‘π‘’
Winter
πœƒ = πΏπ‘Žπ‘‘π‘–π‘‘π‘’π‘‘π‘’ + 15Β°
πœƒ

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Renogy 200W and is the answer not in the manual?

Renogy 200W Specifications

General IconGeneral
Maximum Power Output200W
Cell TypeMonocrystalline
Weight26.5 lbs
Module Efficiency21%
Maximum System Voltage600V DC
Operating Temperature-40Β°F to 185Β°F
Warranty25 years
Cable Length35.4 inches (900mm)
