Renogy RBC20D1U - Dimensions

— 2 —
Dimensions
5.17 in (131.5 mm)
1.59 in
(40.5 mm)
2.75 in
(70 mm)
8.56 in (217.5 mm)
9.31 in (236.5 mm)
20A DC-DC Battery Charger (RBC20D1U)
6.00 in (152.5 mm)
1.59 in
(40.5 mm)
3.56 in
(90.5 mm)
8.56 in (217.5 mm)
9.31 in (236.5 mm)
40A DC-DC Battery Charger (RBC40D1U)
Dimension tolerance: ±0.2 in (0.5 mm)
