Temperature Sensor (optional, not polarity sensitive)
Bluetooth Module communication (optional)
Mounting Recommendations
Never install the controller in a sealed enclosure with flooded batteries. Gas can accumulate
and there is a risk of explosion.
1. Choose Mounting Location—place the controller on a vertical surface protected from
direct sunlight, high temperatures, and water. Make sure there is good ventilation.
NOTE
WARNING
3
Place the sensor close to the battery
Do NOT place the Temperature Sensor lug inside the battery cell.
1 2
1 2
