5m
5m
2.5m
2.5m
3 • Controls
The kit contains a TouchDisplay with integrated CO
2
sensor.
This control has to be placed within or near the kitchen due to
the CO
2
measurement.
• The control has to be installed in
the kitchen in case of a closed kitchen.
• The control has to be installed near
the kitchen in case of an open kitchen.
Optionally you can install a timer control with boost function.
You can set a time interval on this control during which the
ventilation system will operate on full capacity. This function
can be used for night cooling for example. During hot summer
months you can flush your house with large volumes of fresh
outside air to cool down the house.
4 • XVKS Presence detector
The XVKS presence detector has to be installed in rooms with a toilet.
Place the detector near the toilet itself If you have a toilet in your bathroom in
order to avoid unnecessary detection (e.g. rapidly entering and leaving the bathroom).
