Renson Cube - 8.2 Pressure curves (calibration)

109
Cube
®
EN
8.2 • Pressure curves (calibration)
When calibrating the system, it is important to take the following pressure curves into account.
Please consult section 9.1.3.3.1 for the calibration procedure.
0
100
200
300
400
500
600
0 50 100 150 200 250 300 350 400 450 500
37,5%
50%
25%
62,5%
75% 87,5%
100%
Fan curve Cube
®
425
Exhaust flow rate (m
3
/h)
∆p (Pa)
