24 • Technical specifications
The complete current technical specification sheet can be found at www.renson.eu
(products
—
> mechanical ventilation
—
> Healthbox 3.0).
• System properties
(Max.) ventilation air flow 475 m³/h (at 135 Pa)
430 m³/h (at 200 Pa)
Supply voltage 230 Vac ±10% (50Hz, 60Hz)
Consumed power fan group - At max. air flow 150m³/h : 28 Watts
- At max. air flow 225m³/h : 35 Watts
- At max. air flow 325m³/h : 53 Watts
- At max. air flow 400m³/h : 80 Watts
- At max. air flow 475m³/h : 85 Watts
Fan - Extremely quiet & energy efficient EC motor with impeller Ø180
- Active variable pressure control: the lowest possible pressure level
is set each time in function of the required discharge rate
Maximum working pressure fan 350 Pa
- Recommended working pressure at design air flow: ≤ 200 Pa
- Guide value of a very good working pressure at design air flow
(conform TV n° 258): ≤ 100 Pa
Connections - 1x Ethernet connection
- 2x USB connection (USB dongle for Wi-Fi connection included)
- Inputs: 3x DIGITAL, 1x ANALOG (0-10V)
Automatic software updates When Healthbox 3.0 is connected to the internet
Fire protection Depressurize the system with valves close

Renson Healthbox 3.0 Specifications

General

Connectivity	Wi-Fi, Bluetooth
Power Supply	230V AC
Color	White
Control	Automatic sensors
Material	Plastic
