Reolink Argus 2E Operational Instruction

4English3 English
Camera Introduction
Micro USB Port
Red Light: WiFi connection failed
Blue Light: WiFi connection succeeded
Blinking: Standby status
On: Working status
• On Smartphone
Download and launch the Reolink App or Client software and follow the onscreen instructions
to finish initial setup.
Scan to download the Reolink App.
Set up the Camera
• On PC
Download path of the Reolink Client: Go to https://reolink.com > Support > App & Client.
Infrared Lights
Daylight Sensor
Status LED
Built-in PIR Motion Sensor
Reset Button
Dierent states of the status LED:
Lens
Built-in Mic
Outdoor Security Mount
Micro SD Card Slot
Speaker

Reolink Argus 2E Specifications

General

Mounting type	Wall
Product color	Black, White
Protection features	Waterproof
International Protection (IP) code	IP65
Operating temperature (T-T)	-10 - 55 °C
Built-in HDD	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Number of cameras	1
DC output current	2 A
DC output voltage	5
Power source type	Battery, DC
Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired & Wireless
Security algorithms	WEP, WPA-PSK, WPA2-PSK
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Digital zoom	6 x
Detect distance	10 m
Number of lenses	-
Sensor type	CMOS
LED type	IR
Infra-red wavelength	850 nm
Number of illumination LEDs	6
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Video formats supported	H.264

Weight and Dimensions

Depth	58 mm
Width	61 mm
Height	96 mm
Weight	230 g
