Reolink Argus 2E Operational Instruction

6English5 English
For better weatherproof performance, always
keep the USB charging port covered with the
rubber plug after charging the battery.
Charge the Battery
Charge the battery with Reolink
Solar Panel (Not included if you
only purchase the camera).
Charge the battery with a
power adapter (not included).
It's recommended to fully charge the battery before mounting the camera outdoors.
Charging indicator:
Orange LED: Charging
Green LED: Fully charged
• Install the camera 2-3 meters (7-10 ft) above
ground. This height maximizes the detection
range of the PIR motion sensor.
• For eective detection, please install the
camera angularly.
Notes on Camera Installation Position
NOTE: If a moving object approaches the
PIR sensor vertically, the camera may fail
to detect motion.
Install the Camera
θ
Mounting Height:
2-3 Meters
PIR Detection Distance:
2-10 Meters
A
B

Reolink Argus 2E Specifications

General

Mounting type	Wall
Product color	Black, White
Protection features	Waterproof
International Protection (IP) code	IP65
Operating temperature (T-T)	-10 - 55 °C
Built-in HDD	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Number of cameras	1
DC output current	2 A
DC output voltage	5
Power source type	Battery, DC
Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired & Wireless
Security algorithms	WEP, WPA-PSK, WPA2-PSK
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Digital zoom	6 x
Detect distance	10 m
Number of lenses	-
Sensor type	CMOS
LED type	IR
Infra-red wavelength	850 nm
Number of illumination LEDs	6
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Video formats supported	H.264

Weight and Dimensions

Depth	58 mm
Width	61 mm
Height	96 mm
Weight	230 g
