Reolink Argus 2E Operational Instruction

8English7 English
Screw the camera to
the mount.
Adjust the camera angle
to get the best field of
view.
Secure the camera by
turning the part on the
mount identified in the
chart clockwise.
NOTE: To adjust the camera angle later, please loosen the mount by turning the upper
part anticlockwise.
Mount the Camera to the Wall
Rotate to separate the base
from the mount.
Drill holes in accordance with the mounting
template and screw the base of the mount onto
the wall. Next, attach the other part of the mount
onto the base.
NOTE: Use the drywall anchors included in the
package if needed.
It is suggested to use the security bracket to install the camera when mounting it outdoors.
1 2
3 4 5

Reolink Argus 2E Specifications

General

Mounting type	Wall
Product color	Black, White
Protection features	Waterproof
International Protection (IP) code	IP65
Operating temperature (T-T)	-10 - 55 °C
Built-in HDD	No
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Number of cameras	1
DC output current	2 A
DC output voltage	5
Power source type	Battery, DC
Type	IP security camera
Placement supported	Indoor
Connectivity technology	Wired & Wireless
Security algorithms	WEP, WPA-PSK, WPA2-PSK
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Digital zoom	6 x
Detect distance	10 m
Number of lenses	-
Sensor type	CMOS
LED type	IR
Infra-red wavelength	850 nm
Number of illumination LEDs	6
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Video formats supported	H.264

Weight and Dimensions

Depth	58 mm
Width	61 mm
Height	96 mm
Weight	230 g
