Reolink Argus 3 Pro User Manual

Reolink Wireless Battery-powered Camera
9
Argus Eco
Note:
There is no skin and wall mount for Argus Eco, and there is just one mounting
template. Except for the above differences, others are the same as Argus 2.
Argus PT
Note:
Except for the above parts, the surveillance sticker, quick start guide, reset needle
and USB cable are the same as others, but just one pack of screw in this box.
Install a Rechargeable Battery
Argus PT*1
Mounting Template*1
Bracket*1
Strap*1
Slide the battery downward
and lock it firmly.
Check the button status to see
if the battery is installed
correctly.
Argus Eco*1

Reolink Argus 3 Pro Specifications

General

Type	IP security camera
Luminous flux	230 lm
Day/night mode	Yes
Color temperature	6500 K
Placement supported	Outdoor
Connectivity technology	Wireless
Form factor	-
Mounting type	Ceiling/wall
Product color	White
LED indicators	Status
International Protection (IP) code	IP65
Sensor type	CMOS
Optical sensor size	1/3 \
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	10 m
Number of illumination LEDs	6
Total megapixels	4 MP
Maximum resolution	2560 x 1440 pixels
Video formats supported	H.265
Number of cameras	1
Field of view (FOV) angle	122 °
Digital zoom	16 x
Audio system	2-way
Security algorithms	WPA-PSK, WPA2-PSK
Alert notification type	E-mail, Text alert message
Motion sensor technology	Passive infrared (PIR) sensor
Intelligent Video Surveillance (IVS) system features	Human detection
Ethernet LAN	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Power source type	Battery, USB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Operating temperature (T-T)	-10 - 55 °C

Weight and Dimensions

Depth	121 mm
Width	56 mm
Height	90 mm
Weight	330 g
