Reolink Argus 3 Pro User Manual

Reolink Wireless Battery-powered Camera
18
Attach the Camera to a Tree
Remove the Camera
Magnet (for Argus 2 only)
Thread the provided
strap to the mounting
plate.
Fasten the mounting
plate to a tree.
Follow the steps 3-5 in
the wall mounting to
finish installation.
Press the security mount
button to remove the
mount out.
Unscrew the camera from
the security mount.
Put up the skin,
provided in the packa
ge, for Reolink
Argus 2 camera.
There is an anti-falling
Safety rope. Please fasten
the other end of the rope
to the wall mount when
mounting it into a wall.
Stick the camera to the
wall mount and twist
the camera to adjust
direction.

Reolink Argus 3 Pro Specifications

General

Type	IP security camera
Luminous flux	230 lm
Day/night mode	Yes
Color temperature	6500 K
Placement supported	Outdoor
Connectivity technology	Wireless
Form factor	-
Mounting type	Ceiling/wall
Product color	White
LED indicators	Status
International Protection (IP) code	IP65
Sensor type	CMOS
Optical sensor size	1/3 \
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	10 m
Number of illumination LEDs	6
Total megapixels	4 MP
Maximum resolution	2560 x 1440 pixels
Video formats supported	H.265
Number of cameras	1
Field of view (FOV) angle	122 °
Digital zoom	16 x
Audio system	2-way
Security algorithms	WPA-PSK, WPA2-PSK
Alert notification type	E-mail, Text alert message
Motion sensor technology	Passive infrared (PIR) sensor
Intelligent Video Surveillance (IVS) system features	Human detection
Ethernet LAN	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Power source type	Battery, USB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Operating temperature (T-T)	-10 - 55 °C

Weight and Dimensions

Depth	121 mm
Width	56 mm
Height	90 mm
Weight	330 g
