Reolink Duo 4G

English English13 14
Drillholesinaccordancewiththemountingtemplate.Securethemountingplatetothewall
withtheuppertwoscrewsandhangthecameraonit.Thenlockthecamerainposition
withthelowerscrew.
Mount the Camera to the Wall
NOTE: Use the drywall anchors inclued in the package if needed.
θ
1
2
θ
θ
Install the Camera
• Install the camera 2-3 meters
(7-10 ft) above the ground. This
height maximizes the detection
range of the PIR motion sensor.
• For better motion detection
performance,pleaseinstallthe
camera angularly.
NOTE: If a moving object
approaches the PIR sensor
vertically,thecameramayfail
to detect motion.
θ
Mounting Height:
2-3 Meters
PIR Detection Distance:
2-10 Meters
