Reolink RLC-510WA User Manual

Reolink Wireless Camera
User Manual
72
2. Here you can check the camera’s basic information such as camera model and
UID. And check System Info section about its firmware information.
Device Password
To access and use camera, a password is required. The default username is admin
and password is blank (no password). When you set up the camera for the first
time, it’ll ask for creating a password before you can access the camera.
Change Device Password
1. Launch Reolink App and tap settings icon > Advanced > Change Device
Password.
Device name
Camera name
Model
camera model No.
UID
starts with 9527xxxxxxxx
Storage
SD card storage
Network Info
Camera IP address
Firmware Ver
camera firmware version

Reolink RLC-510WA Specifications

General

Number of cameras	1
Video streaming	Yes
Total megapixels	5 MP
Maximum resolution	2560 x 1920 pixels
Video compression formats	H.264
Form factor	Bullet
Mounting type	Ceiling/wall
Product color	White
Protection features	Waterproof
International Protection (IP) code	IP66
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	WPA-PSK, WPA2-PSK
Bluetooth	No
Number of users	20 user(s)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet interface type	Fast Ethernet
Supported network protocols	HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
Type	IP security camera
Placement supported	Outdoor
Connectivity technology	Wired & Wireless
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Mobile operating systems supported	Android, iOS
Fixed focal length	4 mm
Maximum aperture number	2
Sensor type	CMOS
Optical sensor size	1/2.7 \
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	30 m
Number of illumination LEDs	18
DC output current	1 A
DC output voltage	12
Power source type	DC
Power consumption (max)	12 W

Weight and Dimensions

Length	186 mm
Weight	415 g
Diameter	67 mm
