The Solar Siren contains a sophisticated radio
receiver. However, reception of radio signals can be
affected by the presence of metallic objects within the
vicinity of the Solar Siren. It is therefore important to
mount the Solar Siren a minimum distance of 1m
away from any external or internal metalwork, (i.e.
drainpipes, gutters, radiators, mirrors etc).
Ensure that the position selected for the Solar Siren
is within effective range of the Control Panel, (refer to
“Testing the Control Panel & Remote Control”).
Installing the Solar Siren
1. Remove the fixing screw from the bottom edge of
the Solar Siren Siren housing and carefully hinge off
the front cover. All electronic components are
housed within the front cover.
2. Hold the mounting plate in position and mark the
positions of the four mounting holes (a spirit level
placed on the casing will ensure a perfect level).
Drill four 6mm holes and fit the wall plugs.
3. Fit the two 30mm fixing screws in the top holes
leaving approx. 10mm of the screw protruding.
4. Fit the top keyhole slots of the mounting plate over
the screw heads. Adjust the mounting plate and
adjust the screws until they form a neat fit with the
mounting plate with minimal movement
5. Secure the mounting plate in position using the two
25mm fixing screws in the bottom fixing holes.
6.
Ensure that the Siren’s main configuration switch
on the LED Indicator board is set to "Siren".
