Retsch PP40 - Insertion of Pellet Press Rings and Aluminum Cups of the PP40

08.02.2012 Retsch GmbH 15 0002
Insertion of pellet press rings and aluminum
cups of the PP40
A
The press ring P or the aluminum cup will be placed into the
press tool by hand in the front position of the tool slide and
will be filled with sample material. (Filling funnel T to be
used) The filling quantity ranges from 8 to 12 ml, depending
on the material.
During sample preparation, the material to be pressed can be
mixed with a standard binder.
The tool slide must be moved into the pressing position (in
the back), it locks into place and the housing lid must be
closed.
Only start the PP40 with the provided rings or alu cups.
Mechanical components can become damaged.
Fig.8 Insertion of pellet press rings
Abb.10 Einsetzen Probenpressring
Abb.7 Bedienfeld
Fig.9 Filling funnel
T
P
T
