Revolabs 03-HDEXEC4EU - Serial Command Reference Table; Executive HD System Serial Syntax

- 17 -
String Table:
The following table represents the serial syntax of the Executive HD system. Any command marked
with an asterisk will only function if the Base Station has Gold Enabled by entering that systems
unlock code. (See Revolabs HD Gold Control Panel)
Argument
Command
Channel#
Value
set
lock*
1-8 = ch 1-8
0 = Mic Lock Off
1 = Mic Lock On
set
mute
1-8 = ch 1-8
0 = Unmute Mic
1 = Mute Mic
set
mute
A = All Mics
0 = Master Mute Off
1 = Master Mute On
2 = Master Mute Toggle
3 = Mute All
set
gain*
1-8 = ch 1-8
0 = 0db Absolute
1 = -0.5db Absolute
2 = +0.5db Absolute
80-120 = -10db - +10db in 0.5db increments
get
lock*
1-8 = ch 1-8
get
mute
1-8 = ch 1-8
A = Master Mute
get
gain*
1-8 = ch 1-8
get
type*
1-8 = ch 1-8
get
batt
1-8 = ch 1-8
val
lock*
1-8 = ch 1-8
0 = Mic Lock Off
1 = Mic Lock On
val
mute
1-8 = ch 1-8
0 = Unmuted
A = Master Mute
1 = Self Muted (TT Master Mute Mode)
2 = Muted
3 = Microphone Off
4 = Microphone Out of Range*
5 = Microphone Charging*
val
gain*
1-8 = ch 1-8
80-120 = -10db - +10db in 0.5db increments
val
type*
1-8 = ch 1-8
0 = Lapel (Wearable)
1 = Tabletop Omnidirectional
2 = Tabletop Directional
3 = XLR Adapter
4 = Countryman Adapter
val
batt
1-8 = ch 1-8
0 = empty
1 = 25%
2 = 50%
3 = 75%
4 = 100%
