Revolectrix GT500 User Manual

Troubleshooting
.
Safety Code/Message
Problem
Cannot
Load an
Empty Preset
Attempting to load a blank/empty User Preset.
Bad Cell Count
Check Wiring
Check the balance connector or adapter.
Check
Connections
Check the main discharge connectors.
Mains Lead
Reversed
Check the battery pack to charger connections. Battery positive connects to
charger red terminal and battery negative connects to charger black terminal.
Maximum Current
Exceeded
Check the wiring for a loose connection. Check the supply wiring too.
Battery Voltage
Too High
Check the main discharge connectors for a loose connection.
Supply Voltage
Above High
Voltage Limit
Supply voltage is too high.
Supply Voltage
Below Low
Voltage Limit
Supply voltage is too low.
Cap. Limit
Exceeded
The charge/discharge capacity has reached the Chg Cap Limit / Disch Cap
Limit option setting.
Charge Timeout
Exceeded
The charge/discharge time elapsed has reached the Chg Timeout / Disch
Timeout option setting.
Amp. Limit
Exceeded
Check the wiring for a loose connection.
Batt & Cell Sum
Does Not Add Up
Check Wiring
Check the balance connector or adapter.
Supply V Exceed
Regen V Max
Switching To
Internal Disch.
During regenerative discharge, the supply voltage has reached the Regen V.
Max. option setting.
Temp. Limit
Exceeded
High internal temperature warning. Check fan operation.
Pack Below 3.0V
Use Regen Disch
The pack voltage is too low.
Cell Volts Diff
More Than 150mV
Amp Limit to 1A
Safety charge activated due to cell volts range too high.
Supply Amp
Limit Reached
Chg Amp Reduced
Supply amps has reached or exceeded the Smart Power Management setting.
Low
Cell Voltage
The cell voltage is out of range.
High
Cell Voltage
The cell voltage is out of range.
DC Supply
Detected
Check supply connections. Do not attempt a regenerative discharge into a DC
power supply.
