ILLUSTRATED PARTS MANUAL:
FLOWLINE COMB & WIRE
BINDER RANGE
SECTION 9 – HANDLE LOCKS
MODELS CB405E, WB705E
Removal :-
1. Carry out previous sections where applicable.
2. Unscrew 2 off torx head screws from handle locking spindle, remove screws and washers.
3. Pull handle locking cams and spindle out of side frame locations.
Replacement :-
1. Fit handle locking cams into side frame locations, cam marked R - right hand side frame, cam
marked L – left hand side frame.
2. Insert spindle into bores of cams, checking that cam levers are in line.
3. Place washer onto screws and screw into threaded hole at the ends of handle locking spindle,
tighten.
