REXON M2507R - Table of Contents; Product Specifications

2 3
2 3
SECTION PAGE
Product Specifications .............................................................................
2
Power Tool Safety ....................................................................................
3
Compound Miter Saw Safety ................................................................... 5
Electrical Requirements and Safety...........................................................
7
Tools Needed for Assembly ..................................................................... 8
Carton Contents ....................................................................................... 9
Know Your Miter Saw.................................................................................
10
Assembly ................................................................................................. 11
Adjustments ............................................................................................. 15
Operation ................................................................................................. 21
Maintenance ............................................................................................ 33
Troubleshooting Guide ............................................................................ 34
Parts List ................................................................................................ 35
MOTOR
Power Source ..................................................................... 220V~ 50Hz
Speed ................................................................................. 4800 min
-1
(No load)
Brake .................................................................................. Electric
Double Insulated ................................................................. Yes
BLADE SIZE
Diameter.............................................................................. 254 mm
Arbor size............................................................................ 25.4 mm w/a 16 mm
reducer
ROTATING TABLE
Diameter.............................................................................. 32.4 mm
Miter Detent Stops .............................................................. 0°, 22.5°, 45° R & L
Bevel Positive Stops ........................................................... 0, 45° L
CUTTING CAPACITY
Crosscut .............................................................................. 66.7 mm x 141.3 mm
Miter 45° R & L .................................................................... 66.7 mm x 88.9 mm
Bevel 45° L .......................................................................... 39.7 mm x 141.3 mm
45° Miter and 45° Bevel ....................................................... 39.7 mm x 88.9 mm
Crown Molding Nested Against Fence................................. 108 mm
TABLE OF CONTENTS
PRODUCT SPECIFICATIONS
