REXON M2507R - Parts List for Schematic B

36 37
36 37
10 IN. (254 MM) MiterMate
TM
COMPOUND MITER SAW
PARTS LIST FOR SAW SCHEMATIC B
I.D. Description Size Q’ty I.D. Description Size Q’ty
0824 PIVOT SHAFT 1 2VE6 BASE 1
0826 NEEDLE POINTER 1 2VE8 RIGHT-PIVOT-SUPPORT 1
0828 ROTATION SLIDE PLATE 1 2VE9 LEFT-PIVOT-SUPPORT 1
081U SUPPORT 1 2VEB RIGHT-FENCE 1
0D7W CLEVIS PIN 1 2VEC LEFT-FENCE 1
0D7Z KNOB-HANDLE 1 2VED RIGHT-ASSIST-FENCE 1
0G81 SADDLE 2 2VEE LEFT-ASSIST-FENCE 1
0J4D FLAT WASHER φ5*10-1 2 2VEF RUGHT-CLAMP-HANDLE 1
0J4E FLAT WASHER φ6*13-1 4 2VEH LEFT-CLAMP-HANDLE 1
0J4J FLAT WASHER φ10*20-2 1 2VEL BOLT 2
0J58 FLAT WASHER φ5*14-1 4 2VEN PLUNGER-HOUSING 2
0J7G FLAT WASHER 3/8*29/32-1/8 1
2VEP SHAFT 1
0JAZ WAVE WASHER WW-6 2
2VES LEFT-ARM-MITER 1
0JBH DISC SPRING WASHER φ10 1
2VET RIGHT-ARM-MITER 1
0JG7 PARALLEL KEY 4*4-12 1
2VEU LEFT-EXTENSION-WING 1
0JMM O-RING 1
2VEV RIGHT-EXTENSION-WING 1
0JPE HEX. HD. BOLT M6*1.0-20 3
2VEW COLLAR 2
0JPU HEX. HD. BOLT M8*1.25-20 2
2VFS COVER 1
0JX3 HEX. SOC. SET SCREW M5*0.8-8 2
2VFT ROLL PIN 2
0JXA HEX. SOC. SET SCREW M6*1.0-12 2
2VGG SPECIAL BOLT 2
0JZD HEX. SOC. SET SCREW M5*0.8-10 1
2VGR LEVELING PAD 2
0JZF HEX. SOC. SET SCREW M6*1.0-10 4
2VMA CUSHION 2
0K24 HEX. SOC. HD. CAP SCREW M8*1.25-35 2
2VPG ANGLE PEGULATOR 1
0K2D HEX. SOC. HD. CAP SCREW M8*1.25-25 4
2VT1 COMPRESSION SPRING 2
0K55 CR. RE. COUNT HD. SCREW M5*0.8-8 2
2VT4 CLAMP ASS’Y 1
0K56 CR. RE. COUNT HD. SCREW M5*0.8-12 2
2WEJ BUSH 2
0K7L
CR. RE. ROUND WASHER HD. SCREW
M6*1.0-16 2
2WHR ROLLING WHEEL 2
0KDH CR. RE. PAN HD. SCREW M5*0.8-8 2
2WJC HOLDER LINK 1
0KDJ CR. RE. PAN HD. SCREW M5*0.8-12 2
2WJD HOLDER LINK 1
0KDR CR. RE. PAN HD. SCREW M5*0.8-10 1
2WK5 LINK PLATE 2
0KMR HEX. NUT M5*0.8 T=4 2
2WRW TILTING SCALE 1
0KMS HEX. NUT M6*1.0 T=5 5
2WRZ BRACKET-TILT 2
0KMY HEX. NUT M8*1.25 T=6.5 2
2X5U FLAT WASHER φ5*10-2 2
0KQW LOCK NUT M5*0.8 T=5 2
2X5W RETAINING RING 2
0KQX NUT M6*1.0 T=6 2
30R2 HEX. SOC. HD. CAP SCREW M8*1.25-25 4
0KQZ NUT M10*1.5 T=10 1
30R3 HEX. SOC. HD. CAP SCREW M8*1.25-45 2
20VD
CR. RE. TRUSS HD. ROUND NECK SCREW
M6*1.0-16 2
399N BOLT CLAMP 2
25TE STOP BLOCK (LEFT) 1
399Z PLUNGER HANDLE 1
25TF STOP BLOCK (RIGHT) 1
39A1 PLUNGER HANDLE 1
283G HEX. SOC. HD. CAP SCREW M5*0.8-20 4
39AG NEEDLE POINTER 1
2B5S HEX. HD. BOLT M10*1.5-75 1
39AH NEEDLE POINTER 1
2MC4 UPER TUBE 2
39FR KNOB 2
2MC5 UPER TUBE 2
3CWB CAUTION LABEL 1
2N72 RUBBER INSERT 8
3CWC CAUTION LABEL 1
2SER HOLD DOWN CLAMP ASS’Y 1
