Reyee Ruijie RG-NBS3100 Series User Manual

Ruijie RG-NBS3100 Series Switches Hardware Installation and Reference Guide Product Overview
8
Optical Module
The copper cable is not supported. See Appendix B.
The supported module type may change at any time. Consult Ruijie Networks for the latest
information.
SFP Port
1000Base-X
100Base-FX
Power Supply
 Adapter input
Rated voltage range: 100 V to 240 V
Maximum voltage range: 90 V to 264 V
Frequency: 50/60 Hz
Rated current: 1 A
 Adapter output
Rated voltage range: 12 V DC
Rated current range: 1 A
EEE
Supported
PoE
Not supported
Power
Consumption
8W
Temperature
Operating temperature: 0°C to 50°C (32°F to +122°F)
Storage temperature: -40°C to +70°C (-40°F to +158°F)
Humidity
Operating humidity: 10% to 90% RH
Storage humidity: 5% to 95% RH
Fan
Not supported
Temperature
Alarm
Not supported
Accessing Optical
Module
Information
Not supported
Certification
CE
Earth Leakage
Current
≤ 0.25 mA
Dimensions
(W x D x H)
260 mm x 120 mm x 43.6 mm
Weight
1.2 kg (with package)
Device operation in a residential environment may cause radio interference.
Product Appearance
On the front panel, the RG-NBS3100-8GT2SFP Ethernet switch provides eight 10/100/1000Base-T Ethernet ports, two
SFP ports, one reset button, and one DC power port.
Figure 1-8 Appearance of the RG-NBS3100-8GT2SFP
