3
SC-TSL (07-23) REV-0
Field-Installed Options
Option Description
AG7 Electronic modulation with room thermostat
AG9 Electronic modulation with ductstat and remote temperature selector
CC2 Vertical vent terminal
CC6 Horizontal vent terminal
CE1 Manual shutoff valve, natural gas
CE2 Manual shutoff valve, propane
CL1 Single-stage thermostat
CL9 Electronic modulating room override
CL22 Two-stage thermostat
CL33 Two-stage digital thermostat
CL52 Single-stage digital thermostat
CM1 Locking cover for CL1 thermostat
CM1B Locking cover for CL22 and CL33 thermostats
CP2, CP3, CP4 Indoor disconnect switches (US only)
CP41 Indoor disconnect switch (Canada only)
CS1 Condensate drain flange
SA1 Photoelectric air duct smoke detector
Parameter
Unit of
Measure
Unit Size
100 125 150 175 200 225 250 300 350 400
Input heating
capacity
BTUh 100,000 125,000 150,000 175,000 200,000 225,000 250,000 300,000 350,000 400,000
kW 29.3 36.6 44.0 51.3 58.6 65.9 73.3 87.9 102.6 117.2
Output heating
capacity (80%)
BTUh 80,000 100,000 120,000 140,000 160,000 180,000 200,000 240,000 280,000 320,000
kW 23.4 29.3 35.2 41.0 46.9 52.8 58.6 70.3 82.1 93.8
Air volume
with finger-
baffles
CFM 820–1480
1025–
1850
1235–
2200
1440–
2590
1645–
2960
1850–
3330
2055–
3700
2465–
4440
2880–
5185
3290–
5925
meter
3
/hr
1393–
2514
1741–
3143
2098–
3738
2446–
4400
2795–
5029
3143–
5657
3491–
6286
4188–
7543
4893–
8809
5590–
10,066
Air volume
without finger-
baffles*
CFM 985–3700
1230–
4630
1480–
5555
1725–
6480
1975–
7405
2020–
8330
2465–
9255
2960–
11,110
3455–
12,960
3950–
14,815
meter
3
/hr
1673–
6286
2090–
7866
2514–
9438
2931–
11,009
3355–
12,581
3432–
14,152
4188–
15,724
5029–
18,875
5870–
22,018
6711–
25,170
Temperature
rise
°F
50–90
20–75*
Gas
connection,
natural gas
inch
1/2 3/4
Gas
connection,
propane
1/2
Full load amps
(120V)
amp
1.9
Unit control
amps (24V)
0.83
*High CFM conversion requires removal of the finger baffles. This conversion shall be done by a qualified service agency in accordance with
the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction.
Technical Data
Option Description
BG3A–BG3Z Various relay options
BP4 High- and low-pressure gas pressure safety switches
BW1 Air flow pressure proving switch
CGA Canadian installation rating plate
CN1A–CN3Z Various remote switch options
