Reznor VPS Series User Manual

16

Section 12a
Orifice Pressure Adjustment (VPS/VCS).
* De-rated from 169kBTU to 150kBTU.
** De-rated from 200kBTU to 169kBTU, not suitable for high altitude.
LP Gas 0- 2000 ft (0-610m)
Size
60 80 100 125 150 170 200**
“WC
6.0 5.2 8.2 6.6 7.0 5.7 5.7
USA
LP Gas 0- 2000 ft (0-610m)
Size
60 80 100 125 150 170 200**
“WC
6.0 5.2 8.2 6.6 7.0 5.7 5.7
CANADA
LP Gas 2001– 4000 ft (611-1220m)
Size
60 80 100 125 150 170* 200
“WC
5.8 5.0 8.0 6.4 6.8 6.8 N/A
USA
LP Gas 2001– 4500 ft (611-1371m)
Size
60 80 100 125 150 170* 200
“WC
5.8 5.0 8.0 6.4 6.8 6.8 N/A
CANADA
LP Gas 4001– 6000 ft (1220-1829m)
Size
60 80 100 125 150 170* 200
“WC
5.7 4.9 7.9 6.3 6.7 6.7 N/A
USA
LP Gas 6001– 10000 ft (1830-3048m)
Size
60 80 100 125 150 170* 200
“WC
5.6 4.8 7.7 6.1 6.3 6.3 N/A
USA
