5
B
Q
L
M
H
R
P
S
VPT, VCS/T Models
Part Code Description
B Gas Valve
H Gas orifice
L Pressure Switch
M Gaskets
P Burner Orifice Plate
Q Flame Plate Location (plate not shown)
R Fan Orifice Plate
S Baffle Plate Location (plate not shown)
Not on VCS models
