1 Device Overview
1.1 Description
RF-BM-2652P2(I) is an RF module based on TI lower-power CC2652P SoC, which is a multiprotocol 2.4 GHz wireless
module supporting Thread, Zigbee
®
, Bluetooth
®
5.3 Low Energy, IEEE 802.15.4, IPv6-enabled smart objects
(6LoWPAN), proprietary systems, including the TI 15.4-Stack (2.4 GHz), and concurrent multiprotocol through a
Dynamic Multiprotocol Manager (DMM) driver. It integrates a 48 MHz crystal and a 32.768 kHz crystal, 352 KB of
in-system Programmable Flash, 256 KB ROM, 8 KB of Cache SRAM, and 80 KB of ultra-low leakage SRAM. Its ARM
®
Cortex
®
-M4F core application processor can operate at an extremely low current at flexible power modes. And the
module enables long-range and low-power applications using an integrated +20 dBm high-power amplifier with
best-in-class transmit current consumption at 85 mA. It features a small size, robust connection distance, and rigid
reliability. Optional antenna output modes (PCB, IPEX connector, and half-hole interface) make the module more
convenient for application and development.
1.2 Key Features
• RF Section
- Bluetooth 5.3 Low Energy
- ZigBee, Thread
- IEEE 802.15.4
- IPv6-nabld smart objects (6LoWPAN)
- Proprietary systems
- SimpleLink
TM
TI 15.4-Stack (2.4 GHz)
- Dynamic Multiprotocol Manager (DDM) driver
• TX power: up to +20 dBm with temperature
compensation
• Excellent receiver sensitivity
- -105 dBm for Bluetooth 125 kbps (LE coded PHY)
- -100 dBm for 802.15.4 (2.4 GHz)
• Wide Operation Range
- 1.8 V to 3.8 V single power supply
- Operating temperature: -40 °C to +85 °C
- Storage temperature: -40 °C to +125 °C
• Microcontroller
- Powerful 48 MHz ARM
®
Cortex
®
-M4F processor
- EEBMC CoreMark
®
score: 148
- 2-pin cJTAG and JTAG debugging
- Support OTA upgrade
• Memory
- 352 KB of in-system programmable flash
- 256 KB of ROM for protocols and library
functions
- 8 KB of cache SRAM (Alternatively available as
general-purpose RAM)
- 80 KB of ultra-low leakage SRAM. The SRAM is
protected by parity to ensure high reliability of
operation.
• Ultra-low power sensor controller with 4 KB of
SRAM
- Sample, store, and process sensor data
- Operation independent from system CPU
- Fast wake-up for low-power operation
• Rich Peripherals
- 23 GPIOs, digital peripheral pins can be routed
to any GPIOs
- 4 × 32-bit or 8 × 16-bit general-purpose timers
- 12-bit ADC, 200 kSamples/s, 8 channels
- 2 × comparators with internal reference DAC (1
× continuous time, 1 × ultra-low power)
- Programmable current source
