2 Module Configuration and Functions
2.1 Module Parameters
Table 1. Parameters of RF-BM-2652P2(I)
Chipset
CC2652P
Supply Power Voltage
1.8 V ~ 3.8 V, 3.3 V is recommended
Frequency
2402 MHz ～ 2480 MHz
Maximum Transmit Power
+20.0 dBm
Receiving Sensitivity
-100 dBm @ 802.15.4 (2.4 GHz)
-105 dBm @ Bluetooth 125 kbps (LE Coded PHY)
GPIO
23
Flash
352 KB
ROM
256 KB
SRAM
88 KB
Power Consumption
RX current: 6.9 mA
TX current: 7.3 mA @ 0 dBm
9.6 mA @ 5 dBm
22 mA @ 10 dBm
85 mA @ 20 dBm
MCU 48 MHz (CoreMark): 3.4 mA (71 μA/MHz)
Sensor Controller: 30.1 μA @ Low Power-Mode, 2 MHz, running infinite loop
808 μA @ Active-Mode, 24 MHz, running infinite loop
Standby: 0.94 µA
Shutdown: 150 nA
Support Protocol
Thread, ZigBee, BLE5.3, IEEE 802.15.4, 6LoWPAN, proprietary systems,
SimpleLink™ TI 15.4 stack (2.4 GHz)
Crystal
48 MHz, 32.768 kHz
Package
SMT packaging (1.27-mm half-hole pitch stamp stick)
Dimension
30.0 mm × 16.4 mm × 2.2 mm
Type of Antenna
RF-BM-2652P2: PCB antenna
RF-BM-2652P2I: IPEX connector, ANT pin
Operating Temperature
-40 ℃ ～ +85 ℃
Storage Temperature
-40 ℃ ～ +125 ℃
