RF 812N - Page 22

CODE NO PART NO DESCRIPTION SPECIFICATION QTY
NOTE
1 195006B
Base
1
2S 195016ES
Stand Complete Assembly
1
2-1 195016E
Coolant Pan
1
2-2 195016C2
Leg(Right)
1
2-3 195016C3
Leg(Left)
1
2-4 195051R
Panel
1
3 181114
Vise Jaw Bracket(Front)
1
4 W008
Washer
3/8"x25xt2 2
5 S506
Carriage Screw
1/2"-12*2"L 1
6 S426
Hex. Socket Head Screw
3/8"-16*1-1/2"L 1
7 N001
Hex. Nut
1/2"-12 1
8 W002
Washer
1/2"x28xt2 2
9 S003
Hex. Head Screw
1/2"-12*2"L 1
10 181113-4
Vise Jaw Bracket(Rear)
1
11 181266
Fixed Bolt
1
13 3027-1
Knob
1
14 193057
Knob
1
15 HW007
Washer
∮12x23xt2 1
16 193055
Presure Lump
1
17 S612
Hex. Socker Headless Screw
5/16"-18X1/2"L 1
18 181138B
Acme Nut
1
19 192009A
Acme Screw
1
21 193056
Presure Shaft
1
22 S064
Hex. Head Screw
5/16"-18*5/8"L 2
23 W018
Washer
5/16"x23xt3 2
24 195023B Down Bracket 1
25 S014
Hex. Head Screw
3/8"-16*1-3/4"L 1
26 S015
Hex. Head Screw
3/8"-16*2"L 1
27 W013
Washer
3/8"x20xt2 1
28 HB810
Nut
3/8"-16 2
29 290086
Plastic Round Knob
1
30 193059
Knob W/Shaft
1
37 195058
Packing
4
50 195068
Stop Block
1
51 181130
Thumb Screw
1
52 195067
Stock Stop Rod
1
53 S022
Hex. Head Screw
5/16"-18*3/4"L 1
54 S632
Hex. Socker Headless Screw
1/4"-20*5/8"L 1
55 195024
Cylinder Lower Support
1
56 S013
Hex. Head Screw
3/8"-16*1-1/4"L 2
57 W013
Washer
3/8"x20xt2 2
PARTS LIST
MODEL NO. 812N&812G
-20 -
