(4). DON’T install & use this machine in explosive,
dangerous environment.
E. MAINTENANCE:
(1). DISCONNECT machine from power source when
making repairs.
(2). CHECK DAMAGED PARTS. Before further use of
the tool, a guard or other part that is damaged should be
carefully checked to ensure that it will operate properly
and perform its intended function check for alignment of
moving parts, binding of moving parts, breakage of parts,
mounting, and any other conditions that may affect its
operation. A guard or other part that is damaged should
be properly repaired or replaced.
(3). DISCONNECT TOOLS before servicing and when
changing accessories such as blades, bits, cutters, etc.
(4). MAKE SURE that blade tension and blade tacking
are properly adjusted.
(5). RE-CHECK blade tension after initial cut with a new
blade.
(6). TO RPOLONG BLADE LIFE ALWAYS release
blade tension at the end of each work day.
(7).CHECK COOLANT DAILY Low coolant level can
cause foaming and high blade temperatures. Dirty or
week coolant can clog pump, cause crooked. Cast, low
cutting rate and permanent blade failure. Dirty coolant
can cause the growth of bacteria with ensuing skin
irritation.
(8). WHEN CUTTING MAGNESIUM NEVER use
soluble oils or emulsions(oil-water mix) as water will
greatly intensify any accidental magnesium chip fire. See
your industrial coolant supplier for specific coolant
recommendations when cutting magnesium.
(9). TO PRNMT corrosion of machined surfaces when a
soluble on is used as coolant, pay particular attention to
wiping dry the surfaces where fluid accumulates and
does not evaporate quickly, such as between the
machine bed and vise.
F. SPECTIFIED USAGE:
This machine is used only for general metals cutting
within the range of cutting capacity.
G. NOISE:
A weighted sound pressure level : 80 dB.
H. SAFETY DEVICE:
(1). Interlock switch on pulley cover.
As soon as the pulley cover is open, Machine will stop
with the function of this switch. Do not remove this switch
from machine for any reason, and check it’s function
frequently.
(2). Interlock switch on cutting area as soon as the cover
of cutting area in open, machine will stop at once witch
the function of this switch, do not remove this switch from
machine for any reason, and check it’s function
frequently.
CAUTION :
READ ALL INSTRUCTION CAREFULLY BEFORE USING THIS NACHINE. SAVE THIS MANUAL.
3. SPECIFICATION:
MOTOR 0.55KW ( 3/4HP ),1HP(Option)
Blade Size 19.05 x 0.8 x 2362 ( Carbon Blade )
60Hz
98 164 246 328 (FPM)
29 50 75 100 (MPM)
111 229 341 (FPM)
34 70 104 (MPM)
Saw Blade Speed
50Hz
81 135 203 270 (FPM)
24 41 61 82 (MPM)
95 193 285 (FPM)
29 59 87 (MPM)
MODEL NO. CUTTING CAPACITY 812N 812G
○(mm) 200(8”)
90°
□(mm) 178x305(7”x12”)
○(mm) 127(5”)
45°
□(mm)
120x125
(4 3/4”x4 7/8”)
Dimension L x W x H (mm) 1235x430x1100
N.W / G.W (kgs) 180 / 200 180/200
Packing Measurement (mm)
L x W x H
1385 x 483 x 1143
-3-
