How to Do Customized Output Resolution
Push the [MENU/EFFECT] button to enter the menu items, turn the knob and choose [OUTPUT], push
the knob to confirm. Turn the knob, choose [OUTPUT FORMAT], push knob to confirm and go into the
output format menus, as following:
STANDARD--Standard resolution.
CUSTOM--Used defined resolution setting.
Push knob and go into <CUSTOM> menu:
1. Turn knob on each digital position, and change the value of the digital by the digital buttons on the
front panel.
2. After the digital, push the Knob will add *, means before * is the horizontal size. Same operation for
vertical size:
3. After the digital, push the Knob will add @, means before the @ is the vertical size, and after the @ is
the refresh rate. Only digital 50 or digital 60 supports for the refresh rate. Use the digital buttons to
finish the settings.
4. After input all the values, push knob to enable VSP 516S to output this resolution. VSP 516S will take
5-10 seconds to enable this output resolution.
