How to Set up the Size and Position of the Single Image
Push the [SCALE/CROP] button, and enter the scale function menus, the OLED module show as
follows.
The lights of number button 0~9 turn on, user can adjust the following items by knob or number buttons.
H SIZE: Width setting.
V SIZE: Height setting.
H POS: Horizontal phase setting.
V POS: Vertical phase setting.
RESET: If image quality distorts by improper operation, it can be recover by reset.
How to Set up Image Zoom
The image can be zoom in horizontal or vertical separately, to meet the special effects required.
Push the [MENU/EFFECT] button to go into the menu items, turn the knob and choose [INPUT], push
the knob to confirm. Turn the knob, and choose “ZOOM”, show the menus as following:
V UP--Zoom in vertical and the image will be zoom in to the top direction from its bottom.
V DOWN--Zoom in vertical and the image will be zoom in to the down direction from its top.
V UP/DOWN--Zoom in vertical but in both top and down direction from its middle.
H LEFT--Zoom in horizontal and the image will be zoom in to the left direction from its right.
H RIGHT--Zoom in horizontal and the image will be zoom in to the right direction from its left.
H LIFT/RIGHT--Zoom in horizontal but in both left and right direction from its middle.
CENTER--Zoom in 4 corner direction from center.
.
