RGBlink VSP 516S Quick Start Guide

Address：S603-604 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian Province, P.R.C
Tel: 00865925771197 Fax:00865925771202
Email: rgblinkcs@gmail.com http://www.rgblink.cn
4
Hardware Orientation
Front Panel
Button Instruction
MENU/EFFECT
Menu and effect reuse button
DVI
DVI signal source button
SAVE/PIP1
Save and PIP reuse button
DP
Displayport signal source button
LOAD/PIP2
Load and PIP reuse button
SDI
SDI signal source button
SCALE/CROP
Scale and crop reuse button
BLACK
Black button
H SIZE/H POS
Width and horizontal position
setting reuse button
IMAGE1/
IMAGEA and IMAGE B select
reuse button
V SIZE/V POS
Height and vertical position
setting reuse button
FREEZE
Freeze button
CV1,CV2,CV3
CVBS signal source button
0~9
Number button, use for scale
and custom setting
SVID
S-Video signal source button
OLED Panel
Show operation menu items
VGA
VGA signal source button
Knob
Confirm and adjust LCD menu
YPBPR
YPBPR signal source button
