How to Realize Single Image Switching
1. Boot the system default CV1 to the current input source, if need seamless switching other
source such as DVI, push DVI button.
2. CV1 button light turns off after pushing DVI button. DVI button light is on if the DVI signal is
effective and stable. And if the DVI signal is invalid or no input, DVI button light will flash. The same
method can be switched CV2, CV3, SVID, YPbPr, VGA, SDI and DP.
Note: Only cut switching is supported among the switch of CV1, CV2 and CV3.
How to Set up the PIP
Push the [SAVE/PIP1] or [LOAD/PIP2] button for two times, button led light turn on, and enter the PIP
function menu.
LAYOUT: Can choose PIP layout, the corresponding results are as follows:
PIP L+T PBP L+R PBP T+B
SWAP IMAGE: It can set PIP to swap exchange, when choose ON, it can realize the IMAGE A and
IMAGE B exchange.
ALPHA: Can set the image transparency, the regulating range is among 0 to 16.
SELECT: Can choose to set the size or position of IMAGE A or IMAGE B individually.
To Next Page
