Set [H TOTAL] as 2400 (The total width points of the two screens).
Set [V TOTAL] as 1024 (Horizontal split, so the height is unchanged).
Set [H SIZE] as 1152 ( The screen width of VSP 516S).
Set [V SIZE] as 1024 (The screen height of VSP 516S).
Set [H POS] as 0 (The horizontal position of VSP 516S).
Set [V POS] as 0 (The vertical position of VSP 516S).
(3) The same method, enable the [SPLIT] function for the second VSP 516S.
Set the following values by knob or number button (The operations are same with [SCALE]).
Set [H TOTAL] as 2400 (The total width points of the two screens).
Set [V TOTAL] as 1024 (Horizontal split, so the height is unchanged).
Set [H SIZE] as 1248 ( The screen width of VSP 516S).
Set [V SIZE] as 1024 (The screen height of VSP 516S).
Set [H POS] for 1152 (The horizontal position of VSP 516S, that is the screen width of the first
VSP 516S).
Set the vertical position [V POS] for (The vertical position of VSP 516S, that is horizontal split, so the
vertical value is unchanged).
3. Save
Push the [SAVE/PIP1] button, the key lights, start the SAVE function.
Select the location that need to save, push the corresponding button, such as save to SAVE1, push
[CV1/1] button can complete parameter preservation.
It is automatically load SAVE1, if save to other channel, please push the [LOAD/PIP2] button and
push corresponding button to load the saved parameter.
4. Sketch
